pa0nhc project pages for licensed radio amateurs and sound recording.
PA0NHC was born in march 29 1939 and VHF licensed in 1965. Full licensed in 1980. QTH: De Meern, in the center of The Netherlands, GPS 52.084849, 5.013264.
(C) The use, copy and modification of all info on this site is only permitted for non-commercial purposes,
and thereby explicitly mentioning my radio amateur call sign "PA0NHC" as the original writer / designer / photographer /publisher.

To promote my projects, and hobbyists rebuilding them, i offer
Professional, military quality, double sided PCBs, incl. solder masks, screens and free worldwide postage.
When you order one, consider yourself participating in a kind of crowd funding.

Ask info at :
Most articles are in English language. A few in Dutch language.

Go to All 25 RF related subjects. (1.8-30MHz short wave).
Go to

All 8 VHF related subjects.  (144 MHz and 435 MHz).

Go to All 11 AUDIO related subjects. High Quality microphone electronics.  Classical music recording.
Go to Misc. Hoe PCBs maken.   BAD or GOOD capacitor types?   Lightning damage.   And more . . .
How to The re-installation of OLD SOFTWARE under windows 10.
Get it working.


2nd operator "Sokkie" (Socks)
I understand and like cats.

New PCB designs :

20180113.
Remotely tuned active magnetic receiving antenna.

20171229 / updated 20180103
Directional couplers
28MHz-435MHz
RF output and DC output.

20180102
VHF pre- amplifier.  Low noise, sturdy, hi-IP, 28-435 MHz

PCBs in stock :

0171112
 ARDFRX2m
Single super, 10.7MHz IF, 2m ARDF receiver.

20171029
ARDFrx80 : Single super, 10.7MHz IF, 80m ARDF receiver.

Antenna VSWR sweeper V2
fast and easy display of the VSWR graph of antennas, filters and cables.

Magnetic Near Field Indicator
Tune your magnetic loop antenna for best radiation

"Miniwhip" active wideband receiving antenna
Ip3 = +45 dBm

Transformer matching PCB
for a 10m circumference magnetic loop antenna
for perfect matching at 40m and 80m.

20171020
RF rms power meter
0.5 mW- 200 W
 -3 to +53 dBm. Adjustment-free.

RF rms low power meter 1 uW - 4 mW
-30 dBm to +6 dBm.  Adjustment-free.

Noiseless power supply 12 Vdc / 130 mA
for RFnoise-critical electronics (like Miniwhip).
